Hot selling solid nickel plated copper bus bar with pvc dipping

FOB Reference Price:Get Latest Price
  • >=10 Pieces
    $1.00
Lead Time:
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 3 Negotiable
Customization:
Customized logo (Min. Order: 100 Pieces)
Customized packaging (Min. Order: 110 Pieces)

More

Graphic customization (Min. Order: 100 Pieces) Less
Samples - $5.00 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
RHI
Model Number:
bus bar
Application:
Industrial, new energy car or battery pack
Shape:
Square, various
Length:
1mm~12m
Grade:
Copper
Cu (Min):
99.9%
Alloy Or Not:
Non-alloy
Item:
copper bus bar
Material:
copper
Size:
as your request
Plate:
nickel plated
Insualtion part:
pvc dipping
Hardness:
hard
Certificate:
ROHS,IATF16949
Visting company:
welcome
Supply Ability
Supply Ability:
10000 Piece/Pieces per Day copper bus bar
Packaging & Delivery
Packaging Details
copper bus bar
First in poly bag, then in carton. Or as your request.
Port
Ningbo or Shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 3 To be negotiated
Product Description

Hot selling solid nickel plated copper bus bar with pvc dipping

RHI specialize in custom designing and manufacturing bus bars for automotive, battery bank, power storage, switch gear etc. Custom bus bars can be plated in tin, nickel or silver to suit specific applications. Our technicians can assist customers in developing product design and develp prototypes from client drawings. With copper bus bars, customers can eliminate wiring errors and reduce assembly costs.

Material StandardGB : T2 Copper with Min. 99.9%
DIN: E-Cu58 (Number: 2.0065)
EN: Cu-ETP ( Number: CW004A)
ISO: Cu-ETP
UNS: C11000
JIS: C1100
BS: C101
Other Material also can be customized
Resistance
0.00001Ω

Conductivity
57%

Insulation MaterialPVC Dipping Coating is good performance, Special shaped bus bar can  be put on directly, it is not easy to break when it be bent with many times.
Insulation PerformancePE and PVC are good, PVC dipping is better than PE heat shrink tubes
Flame Retardant/Fire ResistanceUL94-V-0 or upon you request
Leakage  TestingPVC Dipping Sleeves:
In condition of 3500VDC with 30s upon thickness 1.5mm, Leakage is 0.025 MA;
In condition of 5000 VAC with 30s to 60s upon thickness 1.8mm to 2.0mm, Leakage is 0.065 MA;
Or upon your working voltage, we advise to choose better solution.
Surface PlatingNickel, tin or silver plated etc
Plating Thickness:Normally 3um to 12um
or upon customers' request
Salt Spray TestingIn a neutral environment, nickel can bear 240 hours. Silver is lower, tin is lowest
Bending TestingBend 10000 times in 15 radian angle without breakage or fracture.
Temperature Rise TestingDepend on flexible busbar cross-sectional area,
We can offer all temperature rising test report before delivery if you request
Operating Temperature
-45 to +150 ºC

Copper Tensile Strength≥500N
Quote TimeQuotation sheet will be sent in 1-3 working days when receive your enqiury
Sample/Trial Order
Delivery Time
In 5 -15 working days according to different bus bar structure and manufacture process
Quality Management StandardMeet Auto Industry IATF 16949
Eco-friendly Certificate
ROHS, REACH





Busbar tester



Testing Capabilities

Test ProgramsTester Standard Test  Result
Endurance testEndurance meterupon your request
Release force testUniversal material testing machineupon your request
Loop resistance,contact resistance testLoop resistance testing equipmentupon your request
Temperature rising testTemperature rising testerGB/T14048.1-2000
Electric conductivity testConductivity testerYS/T478-2005
Salt spray testSalt spraying testerGB/T2423.17-2008
Thermal ageing, heat vibration testAir exchange aging test machineupon your request
Coating thickness testX-ray coating thickness testerupon your request
Voltage drop testVoltage drop testerupon your request
Application
Customer feedback

We also sell




     Busbar with cover     Flexible busbar     PVC dipping busbar
